8MP IP INDOOR/OUTDOOR MID-SIZE EYEBALL DOME. BLCK HOUSING. FIXED 2.8MM LENS. 98.4 FEET SMART IR. POE CAPABLE. IMD 2.0...

8MP, 1/2.8” CMOS Image Sensor | Low Illuminance, High Image Definition

H.265 & H.264 Triple-Steam Encoding

Outputs Max. 8MP (3840 × 2160) | @25/30 Fps

Intelligent Motion Detect 2.0 | Perimeter Protection

Starlight Support | Max. IR LEDs Length 98 Ft

256GB Micro SD Memory | Built-In Mic | IP67

IPEL-E80F-IRB3

$530.00

Quantity

Our next generation IPEL-E80F-IRB3 4K Starlight AI eyeball camera in Factory Black - and its color-matched mounting accessories - make your next nightclub, restaurant, or black ceiling retail installation fast, 4K, and spraypaint-free. This tough, future-proof compact 8MP POE camera brings 4K low-light video/audio overwatch & “next level” AI metadata detection to meet every video security need.

GREAT CAMERA “GUTS” = GREAT 4K VIDEO
IPEL-E80F uses an 8MP / 4K Starlight video chip that sees full-color video down to 0.007 Lux. In total darkness, dual SmartIR LEDs light up 95+ft into the camera’s 107° field of view for ultra-clear grayscale video. The IPEL-E80F also provides audio pickup with a built-in microphone. Intrusion & tripwire functions are AI-enhanced and enable the IPEL-E80F to dependably detect humans and vehicles and react to defined IVS "tripwire" rules with 95% accuracy.

STEALTHY & SMART
This indoor/outdoor 4K camera’s Factory Black finish and compact design offer the low visibility & damage resistance of a dome, with the easy base installation & scene framing of a bullet camera. Beyond its discrete low observability, the IRW3 version brings our latest camera-based iMD 2.0 AI metadata scene extraction. The camera’s AI scans every frame and detected object datasets are encoded & streamed, too. When recorded on an IC Realtime AI NVR with Object Search, this recorded metadata powers our super easy onscreen “select & find” Object Search. One selection & click scans all the NVR’s iMD 2.0 camera channels to find & display all matches for your review. One click = All channels scanned.

FLEXIBLE, SECURE & FUTURE PROOF
The camera’s 4K UHD resolution and its Starlight chip's low light color bring the pixel density & edge detection needed to capture the finest details, so it’s compatible today & ready for future systems upgrades. IPEL-E80F’s three customizable output streams reach up to a full 4K and down to whatever mix of frame rate & resolution is needed to match network limits, set VMS streams, and fit the needs of older NVRs. Its stream management Ai can compress them into multiple H.264, H.265 formats, and its Smart H.265+ can reduce storage space by up to 70% over standard H.265 on compatible IC Realtime NVRs.

A DEPENDABLE 4K CAMERA CHOICE
IC Realtime's sleek Factory Black IPEL-E80F-IRB3 4K eyeball dome is IP67 weather-rated and can use 12VDC power where 7.6w of PoE isn't available, and supports a 256Gb MSD card for onboard video storage. This little eyeball dome isn’t just physically tough. It’s protected from cyber threats by multiple layers of authorizations & password protections. All network traffic is encrypted in both directions, so our gear now meets the newest network standards.

If you need an easy mount, dependable 4K eyeball dome camera in black with ultra-flexible output streams, multiple screwdriver-fit, color-matched mounting accessories, the industry’s longest warranty, and cutting-edge Ai detection features, you need IC Realtime’s new IPEL-E80F-IRB3.

Image Sensor:	1/2.8” 8 Megapixel progressive CMOS
Effective Pixels:	3840 (H) × 2160 (V)
RAM/Rom:	128MB/ 1GB
Scanning System:	Progressive
Minimum Illumination:	0.007 lux@F1.4 (Color, 30 IRE) 0.0007 lux@F1.4 (B/W, 30 IRE) 0 lux (Illuminator on)
S/N Ratio:	> 56 dB
Illumination Distance:	98.4 ft (30 m)
Illumination On/Off Control:	Auto / Manual
Illumination LEDs:	1
Camera Illumination Type:	IR

IC Realtime products are backed by an industry-leading 10 year warranty.

All orders are shipped F.O.B. from IC Realtime distribution facilities or manufacturer's facilities for drop shipments. Title and risk of loss pass to the customer on delivery to the common carrier or upon customer pickup.

IC Realtime will replace, or at its sole discretion repair without charge, any DVR (Digital Video Recorder), NVR (Network Video Recorder) Camera proved defective in material, workmanship or operation for ten (10) years, subject to warranty conditions and exceptions below.

If during the warranty period, we cannot repair your product, we will replace the product with a working product of the same model, or if the same model is not available, with a comparable product.

TEN (10) YEAR WARRANTY CONDITIONS & EXCEPTIONS:

1. Dated proof of purchase with covered unit serial numbers is required for warranty service. Please include a copy of your receipt or invoice with your return.

2. All goods requiring warranty repair require acquiring a valid Case NUMBER (Case). Case numbers can only be issued by IC Realtime technical representatives via email (tech@ICRealtime.com) or by calling the support line at (954) 772-5327.

3. Service returns must have the issued RMA number displayed on the return shipment carton or label. Returns received without an RMA number visible will be refused and returned to the sender unopened.

4. IC Realtime assumes no risk and shall be subject to no liability for damages or loss resulting from the specific use or application made of the Products. IC Realtime’s liability for any claim, whether based on breach of contract, negligence, infringement of any rights of any party or product liability, relating to the Products shall not exceed the price paid to IC Realtime for such Products or the published (Dealer price at the time of sale ), whichever is less.

5. In no event will IC Realtime be liable for any special, incidental or consequential damages (including loss of use, loss of profit and claims of third parties) however caused, whether by the negligence of IC Realtime or otherwise.

6. For warranty repaired or replaced products, IC Realtime will warrant all replacement parts and repairs for the remainder of the original warranty, or 90 days from the date of IC Realtimerepair/replacement return shipment, whichever is longer.

7. Service and warranty repairs are prorated from the end user date of purchase. For Four (4) years (48 months) after purchase IC Realtime covers 100% of replacement or repair costs. After 4 years (48 months), replacement or repair value will prorate for normal wear & by .83 % per month from date of purchase through the end of warranty period. Replacement, upgrade or repair charges are calculated at standard dealer or MSRP pricing whichever is applicable . Warranty is non-transferrable.

8. Repairs made necessary by reason of misuse, alteration, or accident, or cosmetic damage such as finish fading or scratches & scuffs are not covered under this warranty.

9. Exceptions:

Hard drives, SD cards, storage drives, intercom systems and IR Rings (the illumination ring circuit board, LEDs and Components mounted on the board) are covered for three (3) years.

All Edge series cameras/recorders are covered for seven (7) years after February 1st, 2020 (all sales prior to Feb 1st, 2020 were covered for (3) years). Service and warranty repairs are prorated from the end user date of purchase. For Three (3) years (36 months) after purchase IC Realtime covers 100% of replacement or repair costs. After 3 years (36 months), replacement or repair value will prorate for normal wear & by 1.19% per month from date of purchase through the end of warranty period. Replacement, upgrade or repair charges are calculated at standard dealer or MSRP pricing whichever is applicable. Warranty is non-transferrable.

All Clearview CCTV products are covered for seven (7) years. Service and warranty repairs are prorated from the end user date of purchase. For Three (3) years (36 months) after purchase IC Realtime covers 100% of replacement or repair costs. After 3 years (36 months), replacement or repair value will prorate for normal wear & by 1.19% per month from date of purchase through the end of warranty period. Replacement, upgrade or repair charges are calculated at standard dealer or MSRP pricing whichever is applicable. Warranty is non-transferrable.

All IC HOME series (Dinger, Flooder, Singer, etc) products are covered for seven (7) years after March 31st, 2020 For Three (3) years (36 months) after purchase IC Realtime covers 100% of replacement or repair costs. After 3 years (36 months), replacement or repair value will prorate for normal wear & by 1.19% per month from date of purchase through the end of warranty period. Replacement, upgrade or repair charges are calculated at standard dealer or MSRP pricing whichever is applicable. Warranty is non-transferrable.

All network switches, power distribution boxes, mounting brackets, and accessories are covered for one (1) year.

Any special order product including Cradlepoint, Ubiquiti, NEMA boxes and Designer Line are covered for (1) year.

Designer Line custom coated items are warranted against normal wear and tear such as fading, peeling or cracking. Warranty does not cover scratches, chips or any damages due to negligence, abuse or other causes.

B-stock or open box items are covered for thirty (30) days for product failures only.

After the above stated warranty period there is no warranty of any kind on these components. Any product sold by IC Realtime but not manufactured by IC Realtime is warranted only by the original manufacturer's warranty, no other warranties of any kind is offered or implied.

10. Customers seeking warranty for products not manufactured by IC Realtime need to deal directly with the original equipment manufacturer.

11. Warranty validity periods remain with the original purchase date.

Compression:	H.265; H.264; H.264H; H.264B; MJPEG (sub stream only)
Streaming Capability:	3 Streams
Resolution:	8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 ×1728/2592 × 1944); 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048×1536); 3M (2304×1296); 1080p (1920 × 1080); 1.3M(1280 × 960); 720p (1280 × 720); D1 (704 × 576/704×480); CIF (352 × 288/352 × 240); VGA (640 × 480)
Frame Rate:	Main stream: 3840 × 2160 @ (1–25/30) fps Sub stream: 704 × 576 @ (1–25 fps)/ 704 × 480 @ (1–30 fps) Third Stream: 1920 × 1080 @(1–25/30 fps)
Bit Rate Control:	CBR/VBR
Bit Rate:	H.264: 3 Kbps–8192 Kbps H.265: 3 Kbps–8192 Kbps
Backlight Compensation:	BLC / HLC / WDR(120dB)
White Balance:	Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control:	Auto / Manual
Noise Reduction:	3D DNR
Motion Detection:	Off / On (4 Zone, Rectangle)
Region of Interest:	Off / On (4 Zone)
Flip:	0°/90°/180°/270° (supports 90°/270° with 2688×1520 resolution and lower)
Mirror:	Off / On
Privacy Masking:	Off / On (4 Area, Rectangle)
WDR:	120dB

Ethernet:	RJ-45 (10/100Base-T)
Protocol:	IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Interoperability:	ONVIF (Profile S/Profile G/Profile T); CGI; P2P
Streaming Method:	CBR/VBR
Max. User Access:	20 (Total bandwidth: 64 M)
Edge Storage:	NAS, FTP, SFTP, Micro SD Card (256 GB) Local PC for instant recording
Web Viewer:	IE, Chrome, Firefox, Safari
Management Software:	SmartICRSS, DSS
Smart Phone:	IOS, Android

Lens Type:	Fixed-focal
Mount Type:	M12
Focal Length:	2.8 mm
Max. Aperture:	F1.4
Angle of View:	Horizontal:107°; vertical: 56°
Close Focus Distance:	4.9 ft (1.5 m)
DORI - Detect:	287ft
DORI - Observe:	115ft
DORI - Recognize:	57ft
DORI - Identify:	28ft

IVS:	Tripwire; Intrusion
Advanced Intelligent Functions:	Perimeter Protection, Intelligent Motion Dete

Audio I/O:	Built-in Mic, 1 channel input/ output (RCA port)
Memory Slot:	Micro SD Card (256 GB)
